Belimo H540B - 3-way globe valve DN 40

Name: Belimo H540B - 3-way globe valve DN 40
Brand: Belimo
SKU: H540B
Price: 1174.19 PLN
Availability: BackOrder

Belimo

zł1,174.19

VAT included

zł954.63 tax excluded

Belimo H540B is a 3-way globe valve with G 2 1/4" male thread, rated DN 40, PN 16 and Kvs 25 m³/h. Designed for open and closed water systems and water-side control in ventilation and heating systems.

Suitable for water and water containing up to 50% vol. glycol at a fluid temperature of -10...120°C [14...248°F].

Delivery in approx. 14 days

Belimo H540B – 3-way globe valve

Male-thread valve for open and closed water systems and water-side control in ventilation and heating systems.

Key features

DN 40, PN 16, G 2 1/4" male thread.
Kvs 25 m³/h; stroke 15 mm.
Fluid: water, water containing up to 50% vol. glycol.
Fluid temperature: -10...120°C [14...248°F]. Stem heating is required at fluid temperatures of -10...2°C.
Flow characteristic: A – AB equal percentage, B – AB linear.
Permissible leakage: A – AB max. 0.05% of Kvs value; B – AB max. 1% of Kvs value.
Valve body: CC499K; closing element and stem: stainless steel; stem seal: EPDM O-ring.
Installation permitted from vertical to horizontal relative to the valve axis; installation with the stem pointing downwards is not permitted.

Brand

Belimo
Reference

H540B
EAN13

7630498105753

Kvs

25 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

3-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

A – AB: equal-percentage; B – AB: linear
Permissible leakage

A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value
Pipe connection

External thread
