Belimo H6100S - 2-way globe valve DN 100

Name: Belimo H6100S - 2-way globe valve DN 100
Brand: Belimo
SKU: H6100S
Price: 5547.29 PLN
Availability: BackOrder

Belimo

zł5,547.29

VAT included

zł4,509.99 tax excluded

Belimo H6100S flanged 2-way globe valve, DN 100, PN 16, with a Kvs value of 145 m³/h. Designed to control flow in closed water and steam systems.

Medium temperature: 5...150°C [41...302°F]. Body made of EN-GJL-250 (GG 25).

Delivery in approx. 14 days

Belimo H6100S – 2-way globe valve

Flanged control valve for closed water and steam systems in non-critical applications and for continuous control on the water side of ventilation and heating systems.

Key features

DN 100, PN 16, Kvs 145 m³/h; stroke 30 mm.
Medium: water and steam (Δp/P1 <0,4) and water with a maximum of 50% vol. glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C up to 1600 kPa, 150°C up to 1400 kPa.
Flow characteristic: equal-percentage (VDI/VDE 2173), optimised in the opening range.
Permissible leakage: max. 0,05% of the Kvs value.
Flanged connection in accordance with ISO 7005-2.
Body: EN-GJL-250 (GG 25); plug, stem and seat made of stainless steel; stem seal: PTFE V-ring.

The valve can be installed with the stem from vertical to horizontal; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body. The maximum differential pressure and closing pressure depend on the installed globe valve actuator.
