Belimo H611R - 2-way globe valve DN 15
Price:
zł1,056.39
VAT included
zł858.85 tax excluded
Belimo H611R is a 2-way globe valve with a flanged connection, PN 6. It has a Kvs of 0.63 m³/h and is designed for water-side control in ventilation and heating systems.
Belimo H611R – 2-way globe valve
Valve for closed water systems, designed for water-side control in ventilation and heating systems.
Key features
- DN 15, PN 6; flanged connection in accordance with ISO 7005-2.
- Kvs: 0.63 m³/h; stroke: 15 mm.
- Medium: water or water with a maximum of 50% by volume glycol.
- Medium temperature: -10...120°C [14...248°F]. Stem heating is required at temperatures of -10...2°C.
- Flow characteristic: equal percentage (VDI/VDE 2173), optimised in the opening range.
- Permissible leakage: max. 0,05% of the Kvs value.
- Body: EN-GJL-250 (GG 25); closing element and stem: stainless steel; stem seal: EPDM O-ring.
Installation is permitted from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.
-
Brand
-
ReferenceH611R
-
EAN137630498106002
-
Kvs0.63 m³/h
-
MediumWater, water with up to 50% vol. glycol.
-
Pattern2-way
-
Fluid temperature-10...120°C [14...248°F]
-
Fluid temperature, noteWhen the medium temperature is -10...2°C, shaft heating is recommended.
-
Flow characteristicEqual-percentage characteristic
-
Permissible leakageMax. 0.05% of Kvs value
-
Pipe connectionFlange
