Belimo H640SP - 2-way globe valve DN 40

Name: Belimo H640SP - 2-way globe valve DN 40
Brand: Belimo
SKU: H640SP
Price: 6466.25 PLN
Availability: BackOrder

Belimo

zł6,466.25

VAT included

zł5,257.11 tax excluded

Belimo H640SP is a 2-way globe valve with a partially pressure-balanced plug, flanged connection and specifications DN 40, PN 16 and Kvs 25 m³/h. It is designed for closed water and steam systems in non-critical applications and for control on the water side of ventilation and heating systems.

Medium temperature: 5...150°C [41...302°F]. Flow characteristic: equal percentage.

Delivery in approx. 14 days

Belimo H640SP – 2-way globe valve

A globe valve with a partially pressure-balanced plug, designed for control on the water side of ventilation and heating systems and for closed water and steam systems in non-critical applications.

Key technical data

Type: 2-way; DN 40; PN 16; connection: flange.
Kvs: 25 m³/h; stroke: 15 mm.
Medium: water and steam (Δp/P1 <0,4), water with a maximum of 50% vol. glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C up to 1600 kPa, 150°C up to 1400 kPa.
Flow characteristic: equal percentage, optimised in the opening range.
Permissible leakage: max. 0,05% of the Kvs value.
Valve body: EN-GJL-250 (GG 25); closing element, stem and seat: stainless steel; stem seal: PTFE V-ring.
Flanged connection in accordance with ISO 7005-2.

The valve can be installed with the stem in positions from vertical to horizontal; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.
