Belimo D665NL - 2-way butterfly valve DN 65

Name: Belimo D665NL - 2-way butterfly valve DN 65
Brand: Belimo
SKU: D665NL
Price: 734.04 PLN
Availability: BackOrder

Belimo

zł734.04

VAT included

zł596.78 tax excluded

Belimo D665NL is a 2-way butterfly valve DN 65 with threaded holes in the body and PN 10 / 16 flange connection. Flow parameters: Kvs 50 m³/h and Kvmax 170 m³/h.

Intended for water and water with up to 50% vol. glycol; fluid temperature: -20...120°C [-4...248°F].

Delivery in approx. 14 days

Belimo D665NL – butterfly valve DN 65

2-way butterfly valve with threaded holes in the body, intended for open and closed water systems. It can be used to switch heat generators or cooling equipment on and off.

Key technical data

Design: 2-way; DN 65; PN 10 / 16.
Kvs: 50 m³/h; Kvmax: 170 m³/h.
Fluid: water, water with up to 50% vol. glycol.
Fluid temperature: -20...120°C [-4...248°F].
Maximum differential pressure ∆pmax for DN 65: 300 kPa.
Flow characteristic: 0...60% opening angle – equal percentage; 0...100% opening angle – S-shaped.
Permissible leakage: leakage rate A (EN 12266-1).
Rotation angle: 90°; pipe connection: flange according to ISO 7005-2 and EN 1092-2.
Body: EN-GJS-400-18-LT (GGG 40.3); closing element: Stainless steel AISI 304 (1.4301); seat: EPDM.

Permissible installation position: from vertical to horizontal relative to the stem. Do not install the valve with the stem pointing downwards.
