Belimo EM-ECQ-11F - 11-zone manifold

Belimo EM-ECQ-11F - 11-zone manifold

Belimo
zł2,996.23
VAT included
zł2,435.96 tax excluded

Belimo Energy Manifold EM-ECQ-11F is an 11-zone manifold for closed-loop water systems. The manifold is made of stainless steel, and the valve body is made of brass.

Fluid temperature is 2...70°C [36...158°F], and the flow setting is 0...5 l/min.

Delivery in approx. 14 days
Share

Belimo Energy Manifold EM-ECQ-11F

Model EM-ECQ-11F is an 11-zone manifold designed for closed-loop water systems. It can operate with water or water containing up to 50% vol. glycol.

Key features

  • Number of zones: 11.
  • Operating pressure: 6 bar.
  • Fluid temperature: 2...70°C [36...158°F].
  • Flow setting: 0...5 l/min.
  • Manifold: stainless steel; valve body: brass.
  • Tightness: air-bubble tight, leakage rate A (EN 12266-1).
  • Installation: from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted.
  • Designed for snap-on actuator mounting; the valve is maintenance-free.

The dimensions table for EM-ECQ-11F specifies L: 661 mm and L1: 636 mm.

  • Brand
    Belimo
  • Reference
    EM-ECQ-11F
  • EAN13
    7630498119804

  • Medium
    Water, water with up to 50% vol. glycol.
  • Rotational angle
    90°
  • Fluid temperature
    2...70°C [36...158°F]

Techniczna karta katalogowa

Download (3.29MB)

Instrukcja montażu

Download (1.78MB)

Techniczna karta katalogowa – EM-ECQ-..F

Download (3.29MB)

EU Declaration of Conformity – EM-ECQ-11F

Download (58.13KB)

Environmental Declaration – EM-ECQ..

Download (70.39KB)
