Belimo H215S-J - 2-way stainless steel globe valve
Price:
zł979.13
VAT included
zł796.04 tax excluded
Belimo H215S-J is a 2-way globe valve made of AISI 304 stainless steel, DN 15, PN 25, with Rp 1/2" female thread and Kvs 4 m³/h.
Designed for water and water with up to 50% vol. glycol, at a fluid temperature of 0...130°C [32...266°F].
Belimo H215S-J – 2-way globe valve
Stainless steel valve for controlling flow on the water side of ventilation and heating systems. It is designed for open and closed water circuits.
Key features
- Nominal size DN 15 and nominal pressure PN 25.
- Connection: Rp 1/2" female thread.
- Kvs 4 m³/h; stroke 10 mm.
- Fluid: water, water with up to 50% vol. glycol.
- Fluid temperature: 0...130°C [32...266°F].
- Flow characteristic: equal-percentage, optimised in the opening range.
- Permissible leakage: max. 0.01% of the Kvs value.
- Body, closing element, stem and seat: AISI 304 stainless steel; stem seal: PTFE+FFKM.
Permissible installation position: from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.
-
Brand
-
ReferenceH215S-J
-
EAN137630498105456
-
Kvs4 m³/h
-
MediumWater, water with up to 50% vol. glycol.
-
Pattern2-way
-
Fluid temperature0...130°C [32...266°F]
-
Flow characteristicEqual-percentage characteristic
-
Permissible leakageMax. 0.01% of Kvs value
-
Pipe connectionInternal thread
