Belimo TMC230A-F - damper actuator

Belimo TMC230A-F - damper actuator

Belimo
zł921.27
VAT included
zł749.00 tax excluded

Belimo TMC230A-F damper actuator with 2 Nm torque, AC 100...240 V supply and 3-point Open/Close control. The running time is 35 s / 90°, and the mechanical connection is a form-fit connection measuring 8x8 mm.

Product unavailable
Share

Notify me when available

Interested in this product? Drop us an email and we will let you know when it's available for order.

Belimo TMC230A-F damper actuator

Actuator designed for controlling air dampers in building services systems. According to the technical data sheet, it is suitable for dampers with an area of up to approximately 0.4 m².

Key features and specifications

  • Torque: 2 Nm; nominal supply: AC 100...240 V, 50/60 Hz.
  • Control: Open/Close, 3-point; running time: 35 s / 90°.
  • Direction of movement selected by switch 0 (counterclockwise rotation) / 1 (clockwise rotation).
  • Rotation angle: max. 95°; adjustable mechanical stops on both sides.
  • Manual adjustment using a pushbutton with locking option; mechanical position indicator.
  • Mechanical connection: form-fit connection, 8x8 mm; power and control connection: 1 m cable, 3x 0.75 mm².
  • Power consumption during operation: 2 W; at rest: 0.5 W; sizing power for cable selection: 4 VA.
  • Degree of protection IEC/EN: IP54; protection class IEC/EN: II, reinforced insulation.
  • Ambient temperature: -30...50°C [-22...122°F].

  • Brand
    Belimo
  • Reference
    TMC230A-F

  • AC/DC voltage
    AC 100...240 V
  • Power consumption (running)
    2 W
  • Power consumption (holding)
    0.5 W
  • Rated power
    4 VA
  • Power supply control connection
    Cable 1 m, 3x 0.75 mm²
  • Control type
    Open/close, 3-point
  • Protection rating
    IP54
  • NEMA protection rating
    NEMA 2
  • Enclosure type
    UL Enclosure Type 2
  • Manual override
    Push-button, with locking option
  • Running time (motor)
    35 s / 90°
  • Ambient temperature
    -30...50°C [-22...122°F]
  • Torque
    2 Nm
  • Direction of movement - motor
    Selectable via switch: 0 (rotation to the left) / 1 (rotation to the right)
  • Rotational angle
    95°
  • Mechanical connection
    Form-fit connection 8x8 mm

Techniczna karta katalogowa

Download (1.45MB)

Instrukcja montażu

Download (425.78KB)

Environmental Declaration – TM..

Download (72.22KB)
