Belimo CMV-160-MP - VAV air flow controller DN 160

Name: Belimo CMV-160-MP - VAV air flow controller DN 160
Brand: Belimo
SKU: CMV-160-MP
Price: 1846.23 PLN
Availability: OutOfStock

Belimo

zł1,846.23

VAT included

zł1,501.00 tax excluded

Belimo CMV-160-MP is a VAV controller with damper and air velocity sensor, designed to regulate flow independently of pressure changes in residential ventilation systems. For installation in circular ducts with an internal diameter of DN 160.

Power supply AC/DC 24 V, control DC 0/2 … 10 V or MP-Bus, and flow or damper position feedback signal DC 0/2 … 10 V.

Product unavailable

Notify me when available

Interested in this product? Drop us an email and we will let you know when it's available for order.

Belimo CMV-160-MP VAV controller

The device combines a flow controller, actuator, damper blade and thermal anemometric air velocity sensor. It is used to regulate airflow independently of pressure changes in residential ventilation systems. It is designed for installation in circular ducts with an internal diameter of DN 160.

Key features and parameters

Operating modes: VAV with variable flow and CAV with constant flow.
Control: DC 0/2 … 10 V or MP-Bus; flow or damper position feedback: DC 0/2 … 10 V.
Air velocity measurement range: 0.3 … 7 m/s.
Built-in duct air temperature sensor; values can be read via MP-Bus.
Power supply: AC 24 V, 50/60 Hz / DC 24 V; power consumption 1.5 W during operation and 1 W at rest; rated power 2.5 VA.
Torque: min. 2 Nm at rated voltage; motor running time: 70 s.
Manual adjustment using a magnet; degree of protection IP00.
Connection: 1 m cable, 4 x 0.34 mm2.
Ambient temperature: 0 … 50°C.

In CAV mode, the CLOSED / min / mid / max / OPEN settings are available; mid and OPEN require AC 24 V power. The nominal flow settings are specified by the ventilation unit manufacturer.
