Belimo VRU-M1R-BAC - room pressure controller

Belimo VRU-M1R-BAC - room pressure controller

Belimo
zł2,868.36
VAT included
zł2,332.00 tax excluded

Modular VAV-Universal controller with an integrated Belimo M1R static differential pressure sensor for contaminated media. Designed for pressure control in comfort rooms and sensitive work areas.

Supports BACnet MS/TP, Modbus RTU and MP-Bus and works with a ...-VST actuator. AC/DC 24 V power supply; sensor Δp operating range: -75...75 Pa.

Product unavailable
Share

Notify me when available

Interested in this product? Drop us an email and we will let you know when it's available for order.

Belimo VRU-M1R-BAC

VRU-M1R-BAC is a modular VAV-Universal control device with an integrated Δp sensor for contaminated media. It is used for room pressure control (RP) and cascade room pressure control (RPC). It can work with a ...-VST damper actuator.

Key features and specifications

  • Differential pressure sensor: Belimo M1R, static membrane sensor; functional range -75...75 Pa.
  • Control: communicating, hybrid and modulating; communication via BACnet MS/TP, Modbus RTU or MP-Bus.
  • Y operating range: 2...10 V; adjustable Y operating range: 0...10 V.
  • Power supply: AC/DC 24 V, 50/60 Hz; power consumption during operation: 1.5 W.
  • Power rating for cable sizing: 2 VA plus the connected VST actuator.
  • Power and control connection: 2.5 mm² terminals; actuator connection: AC/DC 24 V, PP-Link for the VST actuator.
  • S1 input enables connection of an external passive or active sensor, or a switching contact.
  • Configuration via Belimo Assistant 2; service socket and NFC interface available.
  • IEC/EN protection rating: IP42; IEC/EN protection class: III, Safety Extra-Low Voltage (SELV).
  • Ambient temperature: 0...50°C [32...122°F].

  • Brand
    Belimo
  • Reference
    VRU-M1R-BAC
  • EAN13
    7630498122750

  • AC/DC voltage
    AC/DC 24 V
  • Power consumption (running)
    1.5 W
  • Rated power
    2 VA
  • Power supply control connection
    2.5 mm² terminals
  • Control type
    BACnet MS/TP Modbus RTU MP-Bus DC 2...10 V DC 0.5...10 V Hybrid (communicating/analogue)
  • Protection rating
    IP42
  • NEMA protection rating
    NEMA 1
  • Enclosure type
    UL Enclosure Type 1
  • Ambient temperature
    0...50°C [32...122°F]

Techniczna karta katalogowa

Download (5.68MB)

Techniczna karta katalogowa – VRU-M1R-BAC

Download (5.69MB)

EU Declaration of Conformity – VRU-M1R-BAC

Download (38.21KB)

Environmental Declaration – VRU..

Download (70.5KB)
