Belimo NR24A-KNX - rotary actuator for ball valves

Belimo NR24A-KNX rotary actuator

NR24A-KNX is a communicating rotary actuator for ball valves. Its integrated KNX (S-Mode) interface allows connection to KNX devices with the appropriate data points. The KNX application supports 2- and 3-way valves with one setpoint, and 6-way valves in 4-pipe systems with two setpoints for heating and cooling.

Key features and specifications

• Motor torque: 10 Nm; rated voltage: AC/DC 24 V, 50/60 Hz.
• Communication: KNX (S-Mode); communication medium: KNX TP.
• Motor running time: 90 s / 90°; adjustable running time: 45...170 s.
• Power consumption during operation: 3.5 W; in standby: 1.2 W; sizing power: 6 VA.
• Power and control connection: 1 m cable, 6x 0.75 mm².
• Allows connection of a passive or active sensor, or a switching contact, and transmission of the signal to KNX.
• Integrated KNX application for 6-way valves and condensation monitoring using a sensor connected to the actuator input.
• Manual adjustment by push-button, with option to lock; mechanical rotation angle limiters and position indicator.
• Setpoint range adaptation on first power-up; configurable using Belimo Assistant 2.
• IEC/EN degree of protection: IP54; IEC/EN protection class: III, Safety Extra-Low Voltage (SELV).
