Belimo SR24P-SR-5 - rotary actuator for valves

Name: Belimo SR24P-SR-5 - rotary actuator for valves
Brand: Belimo
SKU: SR24P-SR-5
Price: 1903.14 PLN
Availability: BackOrder

Belimo

zł1,903.14

VAT included

zł1,547.27 tax excluded

Belimo RobustLine rotary actuator for rotary valves and dampers. Torque 20 Nm, AC/DC 24 V supply, 2...10 V modulating control and operating time 90 s / 90°.

Features a 2...10 V position feedback signal, push-button manual operation and an IP66/67-rated enclosure.

Delivery in approx. 14 days

Belimo SR24P-SR-5 rotary actuator

The RobustLine model is designed for rotary valves and dampers. The Y control signal determines the actuator position, while the U measuring voltage is used to electrically indicate the valve position from 0...100%.

Key features

Torque: 20 Nm; motor operating time: 90 s / 90°.
Rated voltage: AC/DC 24 V; frequency: 50/60 Hz.
Modulating control: 2...10 V; position feedback signal: 2...10 V.
Power consumption: 2.5 W during operation and 0.4 W at rest; sizing power: 5 VA.
Power and control connection: 1 m cable, 4x 0.75 mm² (halogen-free).
IEC/EN degree of protection: IP66/67; IEC/EN protection class: III, Safety Extra-Low Voltage (SELV).
F05 connection flange; ZPV-14 adapter included in the scope of delivery.
Mechanical position indicator and stops for adjusting the rotation angle; standard setting 0...90°.
Push-button manual operation with locking option; requires removal of the housing cover.
Overload protection and automatic stop when the end position is reached.
