Belimo EXT-H625P-315 - pressure-independent 2-way globe valve

Name: Belimo EXT-H625P-315 - pressure-independent 2-way globe valve
Brand: Belimo
SKU: EXT-H625P-315
Price: 10574.31 PLN
Availability: OutOfStock

Belimo

zł10,574.31

VAT included

zł8,597.00 tax excluded

Belimo EXT-H625P-315 is a 2-way globe valve with flow independent of pressure changes, DN 25, PN 16, with a flanged connection. V'nom is 0.80 l/s and the medium temperature is 5...140°C [41...284°F].

Product unavailable

Notify me when available

Interested in this product? Drop us an email and we will let you know when it's available for order.

Belimo EXT-H625P-315

2-way globe valve with a mechanical differential pressure regulator and a flanged connection. Intended for closed water circuits (pH >7) and district heating networks.

Key features

DN 25, PN 16; flanged connection in accordance with EN 1092-2.
V'nom: 0.80 l/s; Kvs theor.: 6.3 m³/h; stroke: 11 mm.
Medium: water or water with a maximum of 30% by volume glycol; medium temperature: 5...140°C [41...284°F].
Maximum differential pressure across the control valve: 1000 kPa. To prevent cavitation, ∆pmax must be calculated in accordance with the design notes.
Flow characteristic: equal percentage; permissible leakage: max. 0.02% of the Kvs value.
Body: EN-GJL-250 (GG 25); permissible mounting position: vertical to ±45° relative to the stem.

Kvs theor. means the theoretical Kvs value used to calculate pressure drop. The flow direction must match the arrow on the body.

Brand

Belimo
Reference

EXT-H625P-315
EAN13

7630498120312

Medium

Water, water with max. 30% vol. glycol.
Pattern

2-way
Fluid temperature

5...140°C [41...284°F]
Differential pressure note

To prevent cavitation during operation, the maximum differential pressure ∆pmax must be calculated in accordance with the design notes.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.02% of Kvs value
Pipe connection

Flange
V'nom [l/s]

0.80
