Belimo EXT-H615P-125 - 2-way pressure-independent globe valve

Name: Belimo EXT-H615P-125 - 2-way pressure-independent globe valve
Brand: Belimo
SKU: EXT-H615P-125
Price: 9384.90 PLN
Availability: OutOfStock

Belimo

zł9,384.90

VAT included

zł7,630.00 tax excluded

2-way globe valve independent of pressure changes, DN 15, PN 16, with flanged connection. V'nom 0.35 l/s; medium temperature 5...140°C [41...284°F].

Product unavailable

Notify me when available

Interested in this product? Drop us an email and we will let you know when it's available for order.

Belimo EXT-H615P-125

2-way globe valve independent of pressure changes, designed for closed water circuits (pH >7) and district heating systems.

Key features

DN 15, PN 16; flanged connection in accordance with EN 1092-2.
V'nom 0.35 l/s (1.3 m³/h); theoretical Kvs value: 2.5 m³/h.
Medium: water or water with max. 30% by volume glycol; medium temperature 5...140°C [41...284°F].
Flow characteristic: equal percentage; permissible leakage: max. 0,02% of the Kvs value.
Maximum differential pressure across the control valve: 1000 kPa. To prevent cavitation, ∆pmax must be calculated in accordance with the design notes.
Body: EN-GJL-250 (GG 25); stroke: 10 mm.
Permissible mounting position: vertically up to ±45° relative to the stem.

Brand

Belimo
Reference

EXT-H615P-125
EAN13

7630498120275

Medium

Water, water with max. 30% vol. glycol.
Pattern

2-way
Fluid temperature

5...140°C [41...284°F]
Differential pressure note

To prevent cavitation during operation, the maximum differential pressure ∆pmax must be calculated in accordance with the design notes.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.02% of Kvs value
Pipe connection

Flange
V'nom [l/s]

0.35
