Belimo 01CT-1FH passive temperature sensor with NTC1k8 output, a 50 mm long, 6 mm diameter stainless steel probe and a 2 m, 2-wire PVC cable.

Can be used as a duct temperature sensor with a mounting flange or as an immersion sensor in combination with a sensor pocket. Protection rating: IP67 and NEMA 4X.

Delivery in approx. 14 days
Share

Belimo 01CT-1FH – passive temperature sensor

Wired sensor for measuring the temperature of air or water. It can be installed in an air duct with a mounting flange or used as an immersion sensor in combination with a sensor pocket.

Key features and specifications

  • Output signal: NTC1k8.
  • Stainless steel probe: length 50 mm, diameter 6 mm.
  • Electrical connection: 2 m, 2-wire PVC cable.
  • Temperature measuring range: -35...100°C [-30...210°F].
  • NTC1k8 measuring current: <0.1 mA @ 25°C [77°F].
  • NTC1k8 accuracy: ±0.5°C @ 25°C [±0.9°F @ 77°F].
  • Protection rating: IP67 and NEMA 4X.
  • Product weight: 0.062 kg.

A mounting flange is used for duct installation, while a sensor pocket is used for immersion measurement; these items are listed as accessories in the documentation.

  • Brand
    Belimo
  • Reference
    01CT-1FH
  • EAN13
    7630498117411

  • Electrical connection
    Cable
  • Measured values
    Temperature
  • Output signal
    NTC1k8
  • Passive temperature sensor output
    NTC1k8
  • Probe length
    50 mm
