Belimo 01CT-1AH - passive temperature sensor with cable

Belimo 01CT-1AH - passive temperature sensor with cable

Belimo
zł63.59
VAT included
zł51.70 tax excluded

Passive Belimo 01CT-1AH temperature sensor with Pt100 output signal. The stainless-steel probe is 50 mm long and 6 mm in diameter; the PVC cable is 2 m long and has 2 wires.

For measuring temperature in an air duct with a mounting flange or as an immersion sensor when used with a thermowell. Protection rating IP67 / NEMA 4X.

Delivery in approx. 14 days
Share

Belimo 01CT-1AH – Pt100 temperature sensor

Passive temperature sensor with a stainless-steel probe and PVC cable. It can be used as a duct temperature sensor with a mounting flange or as an immersion sensor when used with a thermowell.

Key features

  • Output signal: Pt100.
  • Probe length: 50 mm; probe diameter: 6 mm.
  • Electrical connection: 2 m cable, 2-wire.
  • Temperature measuring range: -35...100°C [-30...210°F].
  • Measuring current for Pt100: <1 mA @ 0°C [32°F].
  • Accuracy for Pt..: Class B, ±0.3°C @ 0°C [±0.5°F @ 32°F].
  • Protection rating: IP67 (IEC/EN) and NEMA 4X (NEMA/UL).
  • Medium: air, water.

The mounting flange and thermowell are listed in the documentation as accessories; their use depends on the installation method.

  • Brand
    Belimo
  • Reference
    01CT-1AH
  • EAN13
    7630498100093

  • Electrical connection
    Cable
  • Measured values
    Temperature
  • Output signal
    Pt100
  • Passive temperature sensor output
    Pt100
  • Probe length
    50 mm

Techniczna karta katalogowa

Download (884.87KB)

Instrukcja montażu

Download (962.72KB)

Techniczna karta katalogowa – 01CT-1..

Download (890.02KB)

Environmental Declaration – 01CT..

Download (71.66KB)
