Belimo 01CT-1CH - passive cable temperature sensor

Belimo 01CT-1CH - passive cable temperature sensor

Belimo
zł63.59
VAT included
zł51.70 tax excluded

Belimo 01CT-1CH passive cable temperature sensor with Ni1000 output signal. It has a 50 mm long, 6 mm diameter probe and a 2 m, 2-wire cable.

Delivery in approx. 14 days
Share

Belimo 01CT-1CH – cable temperature sensor

Passive sensor for measuring air or water temperature. It can be used as a duct sensor with a mounting flange or as an immersion sensor in combination with an immersion sleeve. The probe is made of stainless steel and the cable is made of PVC.

Key features

  • Output signal: Ni1000.
  • Probe length: 50 mm; probe diameter: 6 mm.
  • Electrical connection: 2 m, 2-wire cable.
  • Temperature measuring range: -35...100°C [-30...210°F].
  • Measuring current for Ni1000: <0.3 mA @ 0°C [32°F].
  • Accuracy for Ni..: ±0.4°C @ 0°C [±0.7°F @ 32°F].
  • Degree of protection: IP67 and NEMA 4X.

The mounting flange and immersion sleeve are listed in the documentation as accessories.

  • Brand
    Belimo
  • Reference
    01CT-1CH
  • EAN13
    7630498100123

  • Electrical connection
    Cable
  • Measured values
    Temperature
  • Output signal
    Ni1000
  • Passive temperature sensor output
    Ni1000
  • Probe length
    50 mm

Techniczna karta katalogowa

Download (884.87KB)

Instrukcja montażu

Download (962.72KB)

Techniczna karta katalogowa – 01CT-1..

Download (890.02KB)

Environmental Declaration – 01CT..

Download (71.66KB)
