Belimo 01CT-1LH - passive temperature sensor with cable

Belimo 01CT-1LH - passive temperature sensor with cable

Belimo
zł56.21
VAT included
zł45.70 tax excluded

Passive temperature sensor with NTC10k (10k2) output, a 50 mm long and 6 mm diameter probe. Supplied with a 2 m, 2-wire cable.

Delivery in approx. 14 days
Share

Belimo 01CT-1LH is a passive temperature sensor with a stainless steel probe and PVC cable. It can be used as a duct temperature sensor with a mounting flange or as an immersion sensor when combined with a thermowell.

Key features

  • Output signal: NTC10k (10k2).
  • Probe length: 50 mm; probe diameter: 6 mm.
  • Electrical connection: 2 m, 2-wire cable.
  • Measuring range: -35...100°C [-30...210°F].
  • Medium: air, water.
  • Protection rating: IP67 and NEMA 4X.
  • Maximum measuring current for NTC10k (10k2): <2 mA @ 25°C [77°F].
  • Accuracy for NTC..: ±0.2°C @ 25°C [±0.35°F @ 77°F].

The mounting flange and thermowell are listed in the documentation as accessories.

  • Brand
    Belimo
  • Reference
    01CT-1LH
  • EAN13
    7630498100154

  • Electrical connection
    Cable
  • Measured values
    Temperature
  • Output signal
    NTC10k (10k2)
  • Passive temperature sensor output
    NTC10k (10k2)
  • Probe length
    50 mm

Techniczna karta katalogowa

Download (884.87KB)

Instrukcja montażu

Download (962.72KB)

Techniczna karta katalogowa – 01CT-1..

Download (890.02KB)

Environmental Declaration – 01CT..

Download (71.66KB)
In business since 2005
Over 20 years of experience
A trusted partner
Reliable service and customer trust
Technical support
Help with selecting and operating equipment
